Orbea Orca M35I

Orbea Orca M35I
  • Color: Ivory White-Burgundy (Gloss)-Vulcano (Matt)
  • Color: Slate Blue-Halo Silver (Matt)
  • Color: Vulcano-Black(Matt) Black(Gloss)
  • Color: Wine Red Carbon View-Titanium (Gloss)
$3,999.00
Color:
Size: Select size
Wheel Size: 700c

Details

Praise the Light

Orca is our lightweight carbon climbing machine, made for those seeking the perfect partner with which to attack every mountain pass.

Orca isn’t just light. It is 6.7 kg of climbing technology designed to change how you reach the top.

The feeling of a bike this light and efficient is unbeatable, and this instant acceleration, vibration absorption, and responsive handling come from a frame that knows where it needs to be light and where it needs to be stiff.

Dominate the Climbs
Achieving Orca's light weight required many marginal gains, focusing on the details and using the best materials across the range. Considering the bike as a package means working with component and wheel designers right from the start to optimize stiffness and weight.

Stiff Where It Counts. Light Where It Matters
It is possible to make very light bikes; however, if you lose efficiency due to a lack of rigidity, then it makes no sense. When we designed Orca, we started with a target rigidity to ensure that even the strongest climbers could be sure of efficient power transmission. Then we designed Orca to be as light as possible without compromising that number.

Lightweight Ride Feel
The feel of a lightweight bike is unbeatable, that instant response and the feeling of acceleration on every pedal stroke. The lack of inertia means an agile, responsive ride as you carve through the corners and accelerate out the other side.

Sizes:
Measurement47495153555760
Seat Tube (C-T) 440 460 480 500 520 540 570
Top Tube (EFF) 510.3 522.7 535.9 548.5 560.4 576.1 590
Head Tube 110.5 118.2 134.6 152.9 173.1 191.2 218.3
Chainstay 408 408 408 408 408 408 408
BB Drop 72 72 72 70 70 70 70
BB Height 268.5 268.5 268.5 270.5 270.5 270.5 270.5
Wheelbase 971.8 975.4 980 981.2 991.4 1001.9 1015.6
Head Angle 71 71.5 72.2 72.8 73 73.2 73.2
Seat Angle 74.5 74 73.7 73.5 73.5 73.2 73.2
Rake 48 48 48 43 43 43 43
Standover 736.5 748.5 767.5 788.5 808.5 826.5 852.5
Reach 370 375 380 385 391 398 404
Stack 506 515 533 552 572 590 616
Fork Length 365 365 365 365 365 365 365
Trail 66 62.8 58.4 59.9 58.7 57.4 57
Sizes:
SizeHeight
47 61.1"-63.0"
49 63.0"-65.4"
51 65.7"-67.7"
53 68.1"-70.5"
55 70.9"-72.8"
57 73.2"-75.2"
60 75.6"-81.5"

Specs

Frame Orbea Orca carbon OMR 2026, monocoque construction, HS 1,5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, internal cable routing.
Fork Orbea Orca OMR ICR 2024, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1.
Wheels Oquo Road Performance RP35TEAM
Axles Front: Orbea Thru Axle 12x100mm M12x2 P1 Hollow
Rear: Orbea Thru Axle 12x142mm M12x2 P1 Hollow
Tires Vittoria Corsa N.Ext G2.0 Foldable 700x28c
Crankset Shimano 105 R7100 34x50t
Shifters Shimano Di2 R7170
Front Derailleur Shimano 105 Di2 R7150
Rear Derailleur Shimano 105 Di2 R7150
Cassette/Freewheel Shimano 105 R7100 11-34t 12-Speed
Chain Shimano M6100
Brakes Shimano R7170 Hydraulic Disc
Handlebars OC Road Performance RP31, Reach 80, Drop 125
Tape/Grips Orbea Anti-Slippery/Shock Proof
Stem OC Road Performance RP23, -5º
Headset FSA 1-1/2" Integrated Aluminium Cup
Seatpost SP 0.2 Carbon, 27.2mm, Setback 20
Pedals Sold Separately
Saddle Fizik Aliante R5
Extras OC Toolbox TB02PP

* Subject to change without notice.

Videos

Part Numbers

Option UPC MPN
Ivory White-Burgundy (Gloss)-Vulcano (Matt) / 47cm / 700c 08434446816017 S11047AJ
Ivory White-Burgundy (Gloss)-Vulcano (Matt) / 49cm / 700c 08434446816062 S11049AJ
Ivory White-Burgundy (Gloss)-Vulcano (Matt) / 51cm / 700c 08434446816116 S11051AJ
Ivory White-Burgundy (Gloss)-Vulcano (Matt) / 53cm / 700c 08434446816161 S11053AJ
Ivory White-Burgundy (Gloss)-Vulcano (Matt) / 55cm / 700c 08434446816215 S11055AJ
Ivory White-Burgundy (Gloss)-Vulcano (Matt) / 57cm / 700c 08434446816260 S11057AJ
Ivory White-Burgundy (Gloss)-Vulcano (Matt) / 60cm / 700c 08434446816314 S11060AJ
Slate Blue-Halo Silver (Matt) / 47cm / 700c 08434446816031 S11047AL
Slate Blue-Halo Silver (Matt) / 49cm / 700c 08434446816086 S11049AL
Slate Blue-Halo Silver (Matt) / 51cm / 700c 08434446816130 S11051AL
Slate Blue-Halo Silver (Matt) / 53cm / 700c 08434446816185 S11053AL
Slate Blue-Halo Silver (Matt) / 55cm / 700c 08434446816239 S11055AL
Slate Blue-Halo Silver (Matt) / 57cm / 700c 08434446816284 S11057AL
Slate Blue-Halo Silver (Matt) / 60cm / 700c 08434446816338 S11060AL
Vulcano-Black(Matt) Black(Gloss) / 47cm / 700c 08434446816024 S11047AK
Vulcano-Black(Matt) Black(Gloss) / 49cm / 700c 08434446816079 S11049AK
Vulcano-Black(Matt) Black(Gloss) / 51cm / 700c 08434446816123 S11051AK
Vulcano-Black(Matt) Black(Gloss) / 53cm / 700c 08434446816178 S11053AK
Vulcano-Black(Matt) Black(Gloss) / 55cm / 700c 08434446816222 S11055AK
Vulcano-Black(Matt) Black(Gloss) / 57cm / 700c 08434446816277 S11057AK
Vulcano-Black(Matt) Black(Gloss) / 60cm / 700c 08434446816321 S11060AK
Wine Red Carbon View-Titanium (Gloss) / 47cm / 700c 08434446816048 S11047CB
Wine Red Carbon View-Titanium (Gloss) / 49cm / 700c 08434446816093 S11049CB
Wine Red Carbon View-Titanium (Gloss) / 51cm / 700c 08434446816147 S11051CB
Wine Red Carbon View-Titanium (Gloss) / 53cm / 700c 08434446816192 S11053CB
Wine Red Carbon View-Titanium (Gloss) / 55cm / 700c 08434446816246 S11055CB
Wine Red Carbon View-Titanium (Gloss) / 57cm / 700c 08434446816291 S11057CB
Wine Red Carbon View-Titanium (Gloss) / 60cm / 700c 08434446816345 S11060CB
