Orbea Ordu OMX 2024

Orbea Ordu OMX 2024
  • Color: Blue Carbon View - Moondust Blue
  • Color: Carbon Raw - Wine Red Shades
$4,199.00
Color:
Size: Select size
Wheel Size: 700c

Details

NEVER THE SAME AGAIN

Just like triathlon is a competition of multiple disciplines, Ordu is an elegant blend of aerodynamics, weight, handling and ergonomics. Once you have experienced Ordu’s multiple strengths, it is impossible to feel confident with a lesser machine. For those who aim to be the fastest, most efficient and decorated athletes, Ordu is the future. You and triathlon will never be the same again.

PERFECT BALANCE

Historically, considering only the three design factors of aerodynamics, stiffness and weight rarely yeilds dramatic improvement. Big gains in one of the three areas always compromise one or both of the others.

The key to building the best triathlon bike is finding the balance of these targets, and identifying additional performance factors that allow the rider to increase efficiency.

AERODYNAMICS

It required more than 2,500 hours of calculations… Analyzing the frame, fork and cockpit assembly and identifying areas to refine and reduce aerodynamic resistance.

WEIGHT

We analyzed the areas where large amounts of material were being used for rigidity.

ERGONOMICS

Ordu is designed to fit the widest possible range of riders. The ergonomics are easily modified over a huge range with just a few adjustment points, easily adaptable for any rider or race regulations. It doesn’t matter if you’re very flexible or not…Ordu will meet your needs.

THE NEW ORDU IS FOR THE SERIOUS TRIATHLETE LOOKING TO UPGRADE AN EXISTING BIKE TO SOMETHING FASTER AND MORE ERGONOMIC WITH MORE INTEGRATION AND LOWER WEIGHT.

Ordu is also the choice of elite or professional road racers who need a UCI-legal time trial bike. Ordu is the racing platform of many Orbea-sponsored teams, and of course our Orbea Pro Triathletes, Fundacion Euskadi and Ceratizit - WNT Team riders.

Sizes:
FRAME SIZEX-SMALLSMALL / MEDIUMMEDIUM / LARGEX-LARGE
HEAD TUBE LENGTH (mm)59 9696149
CHAINSTAY LENGTH (ACTUAL) (mm)405 405405405
BB DROP (mm)75 757575
WHEEL BASE (mm)971 100710071048
SEAT ANGLE (VIRTUAL)74-78º 74-78º74-78º74-78º
STANDOVER HEIGHT* (mm)746 781781831
BB - FRONT WHEEL AXLE (mm)578 613613654
TRAIL (mm)60 606060
WIDTH (mm)380 380380380
STACK HIGH POSITION (mm)481 516516566
STACK LOW POSITION (mm)451 486486536
REACH (mm)641 665665689
STACK MAX (mm)605 640690740
FRONTPOST INSERTION MIN (mm)40 404040
STACK MIN (W/O FP TRIMMING) (mm)588 595645696
STACK MIN (W/ FP TRIMMING) (mm)515 550550600
REACH MAX (BRIDGE POS. 1) (mm)481 505505529
REACH MIN (BRIDGE POS. 2) (mm)361 385385409
ELBOW RESTS MIN/MAX WIDTH (C-C) (mm)105-195 105-195105-195105-195
TILT**0-15º 0-15º0-15º0-15º
HEIGHT MAX (mm)782 817857906
SEATPOST INSERTION MIN (mm)100 100110110
HEIGHT MIN (RECOMMENDED) (mm)- 724754775
HEIGHT MIN (W/O SP TRIMMING) (mm)683 674714764
HEIGHT MIN (W/ SP TRIMMING) (mm)589 624624675
SETBACK TRAVEL (mm)100 100100100
Sizes:
FRAME SIZERIDER HEIGHT (CM)RIDER HEIGHT (IN)
X-SMALL< 170 < 5'6"
SMALL / MEDIUM170 - 180 5'6" - 5'10"
MEDIUM / LARGE175 - 185 5'8" - 6'0"
X-LARGE> 185 > 6'0"

Specs

Fork Orbea Ordu OMX ICR fork 2021, full carbon, 1" head tube, Thru axle 12x100m, thread M12x2P1, Speed release compatible dropout. UCI Legal.
Frame Orbea Ordu carbon OMX Disc, monocoque construction, HS 1" - 1 1/8" mini tapered, BB 386mm, powermeter compatible, Thru Axle 12x142mm, thread M12x2 P1, Speed release compatible dropout, Internal Cable Routing.

* Subject to change without notice.

Part Numbers

Option UPC MPN
Blue Carbon View - Moondust Blue / 700c 8434446648540 R90405BY
Blue Carbon View - Moondust Blue / 700c 8434446648540 R90405BY
Carbon Raw - Wine Red Shades / X-Small / 700c 8434446648502 R90403BX
Carbon Raw - Wine Red Shades / 700c 8434446648564 R90407BX
Carbon Raw - Wine Red Shades / 700c 8434446648564 R90407BX
Blue Carbon View - Moondust Blue / X-Large / 700c 8434446648601 R90409BY
Carbon Raw - Wine Red Shades / X-Large / 700c 8434446648595 R90409BX
Blue Carbon View - Moondust Blue / 700c 8434446648571 R90407BY
Blue Carbon View - Moondust Blue / 700c 8434446648571 R90407BY
Blue Carbon View - Moondust Blue / X-Small / 700c 8434446648519 R90403BY
Carbon Raw - Wine Red Shades / 700c 8434446648533 R90405BX
Carbon Raw - Wine Red Shades / 700c 8434446648533 R90405BX
