Details
The Mach 6, a true do-it-all superhero.
BUILT TO PARTY
Our Ride builds pair supremely durable Marzocchi Bomber coil shocks with Bomber Z1 air forks. Pro and Team builds feature Fox DHX2 coil shocks and Fox 38 Grip2 forks; ideal set-ups for attacking technical terrain and banging out big days at the park.
PEG THE FUN METER
The Mach 6 brings the benchmark stability and enduro performance of our 29" Firebird and infuses it with the unbridled fun that only 27.5" wheels can generate.
WE’VE SWEATED EVERY DETAIL
Every Mach 6 build option is biased toward getting loose and going hard, but also making sure your bike stays in one piece while you test your limits.
PRODUCT DETAILS:
Get everything you need to know about the Mach 6.
- Aggressive geometry for the ultimate in all-mountain, enduro, bike park, and extreme trail performance
- Phoenix DH inspired longer dw-link® maximizes the Mach 6’s rearward wheel path for erasing square edge bumps and maximizing control
- 158mm rear suspension travel featuring a vertically mounted trunnion metric coil-over or air shocks combined with 160mm front travel for unrivaled suspension performance
- 160mm-travel Fox 38 Grip 2 fork with a DHX2 coil shock on Pro and Team builds delivers legendary park and extreme terrain performance with confidence for the big hits
- Lightweight FOX 36 with Float X2 air shock and FOX Live Valve options maximize pedaling performance while reducing overall weight
- Ride-level builds equipped with the incredible Marzocchi Bomber Z1 Air and Bomber CR coil-over shock for no-hassle performance and maximum fun
- Quick accelerating 27.5” wheels guarantee a nimble, playful ride quality across all build options
- Fits tires up to 27.5x2.6” wide and comes stock with Maxxis Assegai 2.5” tires front and rear
- Hassle-free, full-length, internal cable routing with Pivot’s easy-to-service and ultra-quiet Pivot Cable Port System
- Pivot Tool Dock system compatible with mounts under the top tube and integrated into the underside of the frame
- Pivot’s full carbon frame features size-specific ride tuning, leading edge carbon fiber materials, and Pivot's proprietary hollow core molding technology to ensure that every rider from 4’10” to 6’2” has a bike that feels perfect and performs at the optimum level for their size
- Fits riders between 4’10” and 6’2” with X-Small to Large size offerings
Frame Size | X-Small | Small | Medium | Large |
---|---|---|---|---|
Geo Position | Hi / Lo BB | Hi / Lo BB | Hi / Lo BB | Hi / Lo BB |
A - Seat Tube Length (C-T) | 34.3 cm | 36.8 | 39.4 cm | 43.2 cm |
B - Top Tube Length | 56.2 cm | 58.6 | 61.8 cm | 64.1 cm |
C - Head Tube Length | 8.5 cm | 10 cm | 10.8 cm | 12 cm |
D - Head Tube Angle | 65.5° / 65° | 65.5° / 65° | 65.5° / 65° | 65.5° / 65° |
E - Seat Tube Angle (Eff.) | 76.0° / 75.5° | 76.0° / 75.5° | 76.0° / 75.5° | 76.0° / 75.5° |
F - Chainstay Length | 43.1 cm | 43.1 cm | 43.1 cm | 43.1 cm |
G - Bottom Bracket Height | 35.9 /35.2 cm | 35.9 / 35.3 cm | 35.9 / 35.3 cm | 35.9 / 35.3 cm |
H - Standover | 64.2 / 63.6 cm | 65.9 /65.3 cm | 68 / 67.4 cm | 68.2 / 67.6 cm |
I - Wheelbase | 114.6 / 114.8 cm | 117.3 / 117.4cm | 120.6 /120.8 cm | 123.1 / 123.3 cm |
Stack | 56.4 / 56.8 cm | 57.8 / 58.1 cm | 58.5 / 58.9 cm | 59.6 / 60 cm |
Reach | 41.5 / 41 cm | 43.5 / 43 cm | 46.5 / 46 cm | 48.5 / 48 cm |
Frame Size | Rider Height (cm) | Rider Height (in) |
---|---|---|
X-Small | 147 - 162 | 4'10" - 5'4" |
Small | 162 - 172 | 5'4" - 5'8" |
Medium | 172 - 180 | 5'8" - 5'11" |
Large | 180 - 188 | 5'11" - 6'2" |
X-Large | 188 - 200 | 6'2" - 6'7" |
Specs
Frame | Mach 6 |
---|---|
Fork | Fox Factory 38 27.5", 44mm offset, GRIP2 - 160mm |
Rear Shock | Fox Factory Float X2 |
Wheels | DT Swiss M1900, 30mm - 27.5” 15x110 F/12x157 R |
Tires | Maxxis Assegai 27.5" x 2.5" WT, TR, 3C, EXO+, MAXXTERRA |
Brakes | Sram Code R 4-piston |
Crankset | Race Face Æffect R 32t |
Shifters | Shimano SLX M7100 ISPEC EV 12-Speed |
Cassette/Freewheel | Shimano Deore M6100 10-51t |
Rear Derailleur | Shimano XT M8100 SGS 12-Speed |
Rotors |
Front: Sram Centerline 6-bolt - 200mm Rear: Sram Centerline 6-bolt - 180mm |
Headset | Pivot Precision Sealed Cartridge |
Handlebars | Phoenix Race Low Rise Aluminum - 780mm (XS-SM), 800mm (MD-LG) |
Chain | Shimano CN-M6100 12 Speed |
Tape/Grips | Phoenix Factory Lock-On |
Stem | Phoenix Team Enduro/Trail |
Seatpost | Fox Transfer Factory - 125mm (XS), 150mm (SM), 175mm (MD-LG) |
Saddle | WTB Volt (Medium Width) |
Pedals | Sold Separately |
Hubs | DT Swiss 370 |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Mint Relic / X-Small | 196338174190 | 00M6CV427ABRUH-MNTXSDRPFN | |
Mint Relic / Small | 196338174138 | 00M6CV427ABRUH-MNTSMDRPFN | |
Mint Relic / Medium | 196338174077 | 00M6CV427ABRUH-MNTMDDRPFN | |
Mint Relic / Large | 196338174015 | 00M6CV427ABRUH-MNTLGDRPFN | |
Stealth / X-Small | 196338174442 | 00M6CV427ABRUH-STLXSDRPFN | |
Stealth / Small | 196338174381 | 00M6CV427ABRUH-STLSMDRPFN | |
Stealth / Medium | 196338174312 | 00M6CV427ABRUH-STLMDDRPFN | |
Stealth / Large | 196338174251 | 00M6CV427ABRUH-STLLGDRPFN | 210000010939 |
